Name: Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection
Brand: VVCA
Price: 1 USD

Place of Origin : SHAN DONG CHINA

Brand Name : VVCA

Model Number : YX-60

Packaging Details : PLASTIC BAG INNER,EXPORT CARTON OUTSIDE.

Supply Ability : 70K PER MONTH

MOQ : 200PCS

Price : Pls contact with Linda to get right price

Product Name : Bourdon tube Pressure Gauge

Warranty : 1Y, 1 year

Customized support : OEM, ODM, OBM

Material : stainless steel

Connection : bottom

Size : 60mm

Measuring Range : customized

Window : Glass,Plastic

Accuracy : 1.6%

working voltage : AC220V, DC380V , DC24V

thread : NPT, BSP, BSPT

Port : Qingdao

Certification : CE,ISO9001

Delivery Time : 5-15 WORK DAYS

Payment Terms : TT,LC.PAYPAL,Western Union

ADVANTAGES : Moisture-proof,Wear resistant,Eco-friendly,High-durable

Contact Now

Bourdon tube Pressure Gauge Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection

Name	Bourdon tube Pressure Gauge
Dials Size	1.5"(40mm), 2"(50mm), 2.5“(63mm), 4”(100mm) and 6“ (150mm)
Case	Black steel, ABS or chrome plated
Pressure range	0 -250Mpa,other scale units bar, psi, kg/cm2 etc.optional
Ring	Non, black steel or chrome plated
Movement	Stainless steel
Socket	Stainless steel
Bourdon tube	Phosphor Bronze
Dial plate and pointer	Aluminum
Window	Glass or Plastic
Connection sizes	1/8 for 1.5" case; 1/4 for 2",2.5" case, 3/8"&1/2" for 4",6"case
Connection threads	Metric Thread, NPT, BSP (G, PF), BSPT (ZG, PT)
Mounting	Bottom,back and panel
Accuracy	1.5"(40mm), 2"(50mm), 2.5(63mm)-2.5% 4(100mm) and 6 (150mm)-1.6%
Pressure limitation	Steady: 3/4x full scale value Fluctuation:2/3x full scale value Short time:full scale value

Stainless Steel Bourdon Tube Pressure Gauge 60mm Bottom Connection

If you are interested in our product, please click our website:http://qddzfy.en.alibaba.com/
